| Kirchhoff‘s laws, leyes de Kirchhoff (Electrónica - Electronics ), (1) En cualquier red, la suma de las corrientes que terminan en un nodo es cero. (2) En cualquier circuito cerrado de una red, la suma algebráica de los productos de resistencia y corriente en las ramas, es igual a la suma de las FEMs que actúan en el circuito. Estas dos leyes fundamentales se aplican a corrientes instantáneas y son de gran valor en el análisis teórico del comportamiento de circuitos electrónicos.
Through experimentation in 1857 the German physicist Gustav Kirchhoff developed methods to solve complex circuits. Kirchhoff developed two conclusions, known today as Kirchhoff‘s Laws.
Law 1: The sum of the voltage drops around a closed loop is equal to the sum of the voltage sources of that loop (Kirchhoff‘s Voltage Law).
Law 2: The current arriving at any junction point in a circuit is equal to the current leaving that junction (Kirchhoff‘s Current Law).
Kirchhoff‘s two laws may seem obvious based on what we already know about circuit theory. Even though they may seem very simple, they are powerful tools in solving complex and difficult circuits.
Kirchhoff‘s laws can be related to conservation of energy and charge if we look at a circuit with one load and source. Since all of the power provided from the source is consumed by the load, energy and charge are conserved. Since voltage and current can be related to energy and charge, then Kirchhoff‘s laws are only restating the laws governing energy and charge conservation.
The mathematics involved becomes more difficult as the circuits become more complex.
Ohm’s law is stated as it takes one volt to push one ampere through one ohm of resistance.
Ohm’s law is the principle law of electricity and is used to determine electrical values.
However, there are times when Ohm’s law would be difficult to use in determining electrical values. This is true in circuits that do not have clearly defined series or parallel connections.
Also, Ohm’s law can be difficult to use if the circuit has more than one power source. In these instances, Kirchhoff’s laws is used.
Kirchhoff stated two laws that described voltage and current relationships in an electric circuit. The first law, know as Kirchhoff’s voltage law, states that the algebraic sum of the voltage sources and voltage drops in a closed circuit must equal zero. This law is actually the rule that states that the sum of the voltage drops in a series circuit must equal the source voltage.
The second law, known as Kirchhoff’s current law, states that the algebraic sum of the currents entering and leaving a point must equal zero. This is the rule that states that total current flow in a parallel circuit will be the sum of the currents through all the circuit branches.
La ley de Ohm se establece que se necesita un voltio para hacer circular un amperio a través de un ohmio de resistencia.
La ley de Ohm es la ley principal de la electricidad y se utiliza para determinar los valores eléctricos.
Sin embargo, hay momentos en que la ley de Ohm sería difícil de usar para determinar los valores eléctricos. Esto es cierto en circuitos que no tienen conexiones en serie o en paralelo claramente definidas.
Además,la ley de Ohm puede ser difícil de usar si el circuito tiene más de una fuente de alimentación. En estos casos, se utilizan las leyes de Kirchhoff.
Kirchhoff estableció dos leyes que describen las relaciones de voltaje y corriente en un circuito eléctrico. La primera ley, conocida como ley de voltaje de Kirchhoff, establece que la suma algebraica de las fuentes de voltaje y las caídas de voltaje en un circuito cerrado debe ser igual a cero. Esta ley es en realidad la regla que establece que la suma de las caídas de voltaje en un circuito en serie debe ser igual al voltaje de la fuente.
La segunda ley, conocida como ley de corrientes de Kirchhoff, establece que la suma algebraica de las corrientes que entran y salen de un punto debe ser igual a cero. Esta es la regla que establece que el flujo de corriente total en un circuito paralelo será la suma de las corrientes a través de todas las ramas del circuito.
 |
